The heat balance and the temperature regime of the building in the building + reflectors during the period of the minimum arrival of solar radiation (December) and the lowest outside air temperatures (January) in the conditions of Karshi are considered. The obtained results confirm the effectiveness of the application of the building + reflectors system.

To test the efficiency and predict the temperature regime of the room with a system of flat reflectors, installed on the north side of the building [1], an experimental installation was constructed on the heliopoly of the Karshi State University.

Preliminary studies of the thermal regime of the room with a system of reflectors installed on the north side of the building showed that the high density of solar radiation coming from the reflector system through the northern light hole leads to a significant excess of the comfortable radiation and thermal regimes in the room. To protect the room from the high intensity of solar radiation, a screening heat receiver is installed in front of the northern light-hole. The natural illumination of the room is provided through the south window.

The temperature regime in the room is determined on the basis of the heat balance in the building + reflectors system.

When preparing the heat balance, the following conditions are accepted:

‒ interacting elements: internal and external air environment, enclosing structures, a system of flat reflectors;

‒ the influence of interior items on the heat balance of the premises is not taken into account;

‒ walls, ceiling ceiling, floor spaces are considered as multi-layered, windows and doors — as single-layer fences;

‒ the walls, combined with the control and tambour rooms, are considered as multi-layered enclosures with air interlayer;

‒ with respect to the environment, the building is treated as a stand-alone facility.

In general, the heat balance of a room is determined by the equation:

Q_ab = Q_hl; (1)

where Q_{аb —} total absorbed heat of solar radiation entering the room, W; Q_{hl —} total heat loss in the room, W. Total solar radiation that has passed into the room:

Q_р = Q_р4 + Q_р5; (2)

Total solar radiation coming through the window Q_р5 and light Q_р3, is determined by the formulas:

Q_р5 = (S_пр5 + D_пр5) F₅; Q_пр3 = (S_пр3 + D_пр3) F₃; (3)

where S_р и D_{р —} density of transmitted direct and scattered solar radiation, W/m²; F₅ and F_{3 —} the area of the glazed surface of the window and the light-bearing area, m².

Direct solar radiation in the lightguard comes from the reflectors:

S_пр3 = S_пр0 + 2 S_пр1 sinγ; (4)

where S_р0, S_{р1 —} direct solar radiation coming from the middle and right + left reflectors, W/m²; γ — angle of incidence of rays on the plane of the heat receiver, deg.

Solar radiation entering the room is absorbed by the internal surfaces and the heat receiver:

Q_ab5 =А_р Q_р5; Q_ab4 =А_r Q_р3; (5)

where А_{р —} the reduced coefficient of absorption of solar radiation by the internal surfaces of the room; А_{r —} coefficient of absorption of solar radiation by the heat receiver. Total heat loss in the room:

Q_hl = Q_hf + Q_a; (6)

where Q_{hf —} heat loss through fences, W; Q_{в —} heat loss by infiltration of air, W.

Heat loss through fences:

Q_hf = К_р F_fen (t_в — t_н); (7)

where К_{р —} reduced coefficient of heat transfer of the fence, W/(m²K); F_{огр —} total surface area of the fence, м²; t_i, t_{e —} temperature of indoor and outdoor air,^оS.

Heat loss by infiltration — air ventilation

Q_v = с_р ρ_в V_в (t_в — t_н); (8)

where с_р — Specific heat of air, J/(kg K); ρ_в — density of air, kg/m³; V_v — volume of ventilated air, m³/s.

Taking (7) and (8) into account, we reduce (1) to the form:

Q_ab = К_р F_fen (t_i — t_e) + с_р ρ V_v (t_i — t_e). (9)

Where do we get:

t_i = t_e + (10)

The reduced heat transfer coefficient of the enclosure is determined by the formula:

К_пр = ; (11)

where К_{i —} heat transfer coefficient i- fencing element, V/(m² К); F_{i —} surface area of the fence element, m²; i= 1, 2, 3, 4, 5 — index of fencing elements.

Heat transfer coefficient of fencing elements:

; (12)

where α_ii and α_{ei —} heat transfer coefficients on the inner and outer surfaces of fencing elements, V/(m² К); R_{i —} thermal resistance of the fence, m² К/V.

Heat transfer on the surfaces of the enclosure occurs by convection and radiation:

α_ii = α_ici + α_iri; α_ei = α_eci + α_eri; (13)

where α_ici and α_{iri —} convective components of heat transfer coefficients, V/(m² К); α_eci and α_{eri —} radiative emission factors, V/(m² К).

Thermal resistance of fencing:

; (14)

where δ_{ij —} thickness of the fence layer, m; λ_{ij —} coefficient of thermal conductivity of the material of the fence layer, W/(m K). j — number of layers in the enclosure.

Coefficient of convective heat transfer on internal surfaces fencing is determined by the formula [2]:

; (15)

where _— average temperature of the inner surface of the fence, ^оS; А — coefficient, depending on the location of the surface.

Coefficients of convective heat transfer at the outer surfaces of the enclosure are determined by the formula [3]:

α_eci = 6,43 + 3,57 w; w≤ 5 m/s; (16)

where w — wind speed, m/s.

Coefficients of heat emission by radiation on the inner surfaces of the fence [4]:

α_iri =; (17)

where σ=5,67×10–⁸ V/(m² К) — the Stefan-Boltzmann constant; ε_вi — the degree of blackness of the inner surface of the element of the fence surface; ε_{впр —} reduced degree of blackness of the inner surfaces of the fence; Т_овi andТ_в — absolute temperature of internal surfaces of fencing and air, К.

Coefficients of heat emission by radiation on the external surfaces of walls, windows and light holes are determined with respect to the outside air temperature:

α_ниi ; (18)

where Т_нi — temperature of the outer surface of the fence, К.

The coefficient of heat emission by radiation on the upper surface of the roof of the ceiling is determined with respect to the temperature of the sky [5]

α_ни2 ; (19)

where Т_{н2 —} temperature of the outer surface of the roof guard, К; Т_о=0,0552 — sky temperature, К.

The blackened heat receiver, due to the absorption of solar radiation, heats up and transfers heat to the air in the room. Heat transfer from the heat collector occurs from two sides: from the inside (towards the room) and from the outside (towards the window). The temperature of the inner and outer surfaces of the heat receiver is not more than 0.2... 0.3^оS. Therefore, the temperature on both surfaces of the heat receiver can be assumed to be the same. The temperature of the heat receiver is determined by the temperature of the internal air and the amount of absorbed radiation [5]:

t_m = t_в + Q_пг4 / α_т; (20)

where α_{т —} the total heat transfer coefficient on the surfaces of the heat receiver, V/(m² К):

α_т = α_тв + α_тн; (21)

α_тв and α_{тн —} heat transfer coefficient on the inner and outer surfaces of the heat sink, V/(m² К):

α_тв = α_твк + α_тви; α_тн = α_тнк + α_тни. (22)

The coefficients of heat transfer by convection on the surfaces of the heat receiver are determined by the formula [5]:

; (23)

; ; ; (24)

where Nu, Gr, Pr — Nusselt number, Grasgof, Prandtl; l_т — The determining size is the height of the heat receiver, m; g — acceleration of gravity, m/s²; t_m — temperature of the heat receiver, ^оС; β — temperature coefficient of air density change, К^-1; ν_в, а_{в —} coefficients of kinematic viscosity and thermal diffusivity of air, m²/s.

The coefficient of heat emission by radiation on the inner surface of the heat receiver is determined with respect to the temperature of the internal air:

α_тви = ; (25)

where ε_т — blackness of the heat receiver surface; F_{m —} surface area of the heat receiver.

The coefficient of heat emission by radiation on the external surface of the heat receiver is determined with respect to the temperature of the inner surface of the glazing

α_тни ; (26)

where Т_в2 — temperature of the inner surface of the glazing of the window, К; ε_с — the degree of blackness of the glazing surface.

Equations (1) — (8) determine the heat balance of the building system + reflectors. The accuracy of the calculation of the heat balance depends on the correct determination of the heat transfer coefficients at the fence surfaces (13) — (19), the heat receiver (21) — (26), and the thermophysical characteristics of the fence construction materials. The real heat balance ensures the prediction of the thermal regime (10), (11), (20) the building + reflectors.

For comparison, the values of the arrival of solar radiation in a room through the southern light-projector with an equivalent area 3 F₃: 3–3F_{3 —} Q_пр5В and a wall of the Thrombus falling on a vertical surface; 4–3F₃ — Q_пр5Г and falling on the floor and walls in the room. As can be seen, with equal light transmitting surfaces, the influx of solar radiation from the reflector system is greater than through the southern light barrier with an equivalent surface 3F₃:

п_в = Q_пр3 /Q_пр5В = 0,86…1,16; п_г = Q_пр3 /Q_пр5Г = 2,01…2,72.

The heat sink functions as a heater. The temperature of the heat receiver varies in proportion to the intake of solar radiation and the air temperature in the room.

In the period from 10–11 hours and up to 15 hours the temperature of the air in the room exceeds the normative value t_i = 20^оS. During this period, it becomes necessary to accumulate an excess of heat from solar radiation.

The given temperature regime in the period of the minimum arrival of solar radiation and the lowest temperatures of the outside air allows us to predict the effectiveness of the system of reflectors installed on the north side of the building during the heating season.
